LSR-1 MINI LED WHITE EMERGENCY LIGHT
Series: LSR-1 | Part #: LSR-1
The Tamlite Lighting LSR-1 Mini LED White Emergency Light offers unparalleled reliability and performance for commercial and industrial settings. With its robust, flame-retardant thermoplastic housing and dual voltage capability, this compact emergency light ensures clear, powerful illumination during power outages. Features like adjustable LED heads, a 90-minute Ni-Cad battery backup, and easy installation options make it a top choice for safety compliance in damp locations. Ideal for ensuring visibility and safety, the LSR-1 is both lightweight and durable, certified to meet rigorous UL standards.
Download Specification SheetFeatures
- Injection-molded, 5VA flame retardant, high impact, thermoplastic housing
- Labor saving fixture design with an easy snap-fit backplate
- Two round, fully adjustable LED heads
- Environmentally friendly Ni-Cad battery
- High-performance optimal light distribution polycarbonate lens
- Test switch and AC power indicator light
- Suitable for wall or ceiling mount
- Dual voltage for 120 or 277V operation
Log in / Register
Specifications
Height: 4.75 Inches
Number Of Lamps: 2
Battery Runtime: 90 Minutes
Length: 9 Inches
Weight: 1.2 Pounds
Lumens: 91 Lumens
Series: LSR-1
Environmental Conditions: Damp Location
Mounting: Surface
Material: Thermoplastic
Battery Size: 3.6v 900 mah
Standard: UL
Stock Code: 0276-9654
Depth: 2.75 Inches
Number Of Batteries: 1
Wattage: 2 Watts
Battery: Ni-Cad
Ordering Information
Part # | Stock Code | Height | Length | Width | Voltage Rating | Mounting |
---|---|---|---|---|---|---|
LSR-1 | 0276-9654 | 4.75 Inches | 9 Inches | -NA- | -NA- | Surface |
LSR-1B | 0286-6272 | 4.75 Inches | 9 Inches | 2.75 Inches | 120-277 VAC | Surface Mount |
LSR-1BHL | 0286-6275 | 4.75 Inches | 9 Inches | 2.75 Inches | 120-277 VAC | Surface Mount |
LSR-1HL | 0285-2679 | 4.75 Inches | 9 Inches | 2.75 Inches | 120-277 VAC | Surface Mount |
LSR-1RC | 0285-2682 | 4.75 Inches | 9 Inches | 2.75 Inches | 120/277 VAC | Surface Mount |
LSR-1SD | 0373-6083 | 4.75 Inches | 9 Inches | -NA- | 120-277 VAC | Surface Mount |
